1969 911E - Motor Question

Hi all,

I recently acquired a 1969 911E in Silver Metallic over Black and have been thoroughly enjoying the car. I have an enormous record book dating back to 1971 (from second owner to last) and have been pouring through it. The motor appears to have been gone through at least three times over the last 50 years and I'm trying to understand what exactly I've got. At some point in the 90's it got 73 S heads and S cams, but it was gone through again in 2013.

The car pulls very hard from 5-7k and you can absolutely notice it coming on/off cam (feels almost like turbo lag power delivery).

The case and transmission are indeed numbers matching, but after a bit of investigating and using my trusty boroscope, I've realized this car has K1819n heads. Based on a few grids I've seen floating around, I think these are 72/73 911T heads (they have casting numbers of 911.104.302.OR). These appear to have valve sizes of 46/40 vs the original E heads of 42/38, but the port sizes are smaller. Maybe the heads were ported to match the S port sizes of 36/35?

Is there a "standard recipe" for hot rodding these 2.0 motors that would include these T heads and perhaps S cams? Any other things I can learn about the motor without taking it apart? I've seen reference in the record book of this being a 2.2...

Thanks!

Attachment 597403

Attachment 597404

Attachment 597405

2.2 for sure, as the heads aren’t comparable with 2.0. Does this still use the fuel injection it came with?

I'd be interested in seeing your paint badge, because the 1969 silver code is unlike any other code found on the badges. This badge is on the left door hinge post.

Quote:

---

Originally Posted by gled49

2.2 for sure, as the heads aren’t comparable with 2.0. Does this still use the fuel injection it came with?

---

Yes - still MFI.

Quote:

---

Originally Posted by davep

I'd be interested in seeing your paint badge, because the 1969 silver code is unlike any other code found on the badges. This badge is on the left door hinge post.

---

The code is 6851 according to the door tag and COA.

Attachment 597464

MFI, ok, is it still using the twin solenoid E injection pump. Pump code and serial numbers on top tell the story. Posable small ports and 2.0E pump could be a good combo. How would u rate the overall performance.

Quote:

---

Originally Posted by gled49

MFI, ok, is it still using the twin solenoid E injection pump. Pump code and serial numbers on top tell the story. Posable small ports and 2.0E pump could be a good combo. How would u rate the overall performance.

---

Here's a picture of the plate on the MFI pump. It reads:

90615401
0408 126 005

Attachment 597513

I'd say it's a relatively slow build to 5k, but once you're there it really moves. Feels strong.

After looking at pump serials, it looks like this is a 2.0 S pump. Can anyone confirm?

If it is indeed an S pump, how would one reconcile that with the T heads? Would 2.2 heads work with the 2.0 S pump?

005 is a 69S pump I'm pretty sure as my 69S has that pump.

Thanks for the photo of the paint badge. The code is correct, but it is not the usual one I see for silver in 1969; possibly due to being a Karmann body. I'd love to know the VIN for reference.
Just for laughs, look at this thread for the "stranger" but more common 1969 silver code:
https://forums.pelicanparts.com/pors...ode-plate.html

Just for reference on paint code 6851…

Quote:

---

Originally Posted by davep

Thanks for the photo of the paint badge. The code is correct, but it is not the usual one I see for silver in 1969; possibly due to being a Karmann body. I'd love to know the VIN for reference.
Just for laughs, look at this thread for the "stranger" but more common 1969 silver code:
https://forums.pelicanparts.com/pors...ode-plate.html

---

Interesting.

VIN is 119220570.

Thanks for the VIN reference, it helps my paint code research.

Thx for the input, we love lots of detail pix.

VIN doesn't look correct, should start with 11920XXXX ??
Bob B

Quote:

---

Originally Posted by SIMI BOB

VIN doesn't look correct, should start with 11920XXXX ??
Bob B

---

What makes you say that? The COA is below.


Attachment 597541

Quote:

---

Originally Posted by SIMI BOB

VIN doesn't look correct, should start with 11920XXXX ??
Bob B

---

Karmann built cars had the extra 2 in the vin ie 11922xxxx to identify them as Karmann built not Porsche built

Quote:

---

Originally Posted by davep

Thanks for the photo of the paint badge. The code is correct, but it is not the usual one I see for silver in 1969; possibly due to being a Karmann body. I'd love to know the VIN for reference.
Just for laughs, look at this thread for the "stranger" but more common 1969 silver code:
https://forums.pelicanparts.com/pors...ode-plate.html

---

thanks for the link…🙏🙏

Note for Brbrbr: the completion date of the CoA is likely the Invoice date or possibly the date of first sale. This can be weeks after actual completion. I have a lot of data on the cars and know actual completion dates for a few, the Invoice date for many, an actual shipping date for one, and date of sale for some. The actual Kardex (a warranty record card) should be available for this car if required. This is a nicely optioned car. BTW, there is a Karmann body # to be found at the rear of the tunnel under the access plate for the shift rod coupling, and around the edge of the opening hidden under the carpet. The Production # (similar format) which is not the same as the VIN as in previous years can be found under the knee pad in the area below the radio opening in the dash.
Regards, Dave

All '73 heads have the same size valves for T , E and S , but the port sizes are different , so if not already done have the ports enlarged to match the intake manifolds . I really like the 2.0S engine , but it was anemic below 5000 RPM so the 2.2
is a good upgrade , but you loose the 2.0 S personality . The 2.0S production engine was the closet engine Porsche built to the race engines , but people don't like them because there's no low end .

Quote:

---

Originally Posted by Richy

All '73 heads have the same size valves for T , E and S , but the port sizes are different , so if not already done have the ports enlarged to match the intake manifolds . I really like the 2.0S engine , but it was anemic below 5000 RPM so the 2.2
is a good upgrade , but you loose the 2.0 S personality . The 2.0S production engine was the closet engine Porsche built to the race engines , but people don't like them because there's no low end .

---

Very insightful. This has me believe it is a 2.0. It is a dog off cam. Once you hit 5k you’re off to the races and it pulls and pulls, but below that is a slog.

Quote:

---

Originally Posted by davep

Note for Brbrbr: the completion date of the CoA is likely the Invoice date or possibly the date of first sale. This can be weeks after actual completion. I have a lot of data on the cars and know actual completion dates for a few, the Invoice date for many, an actual shipping date for one, and date of sale for some. The actual Kardex (a warranty record card) should be available for this car if required. This is a nicely optioned car. BTW, there is a Karmann body # to be found at the rear of the tunnel under the access plate for the shift rod coupling, and around the edge of the opening hidden under the carpet. The Production # (similar format) which is not the same as the VIN as in previous years can be found under the knee pad in the area below the radio opening in the dash.
Regards, Dave

---

Thank you for the note.
